DIZEO™ (LED module to integrate)

Compatible with our Arbane, Vermentino and Réglisse models, the Dizéo™ LED fixture with its optical prism reflecting light, fits perfectly into your architectural, pedestrian or street lighting projects. Its 12 long-lasting, low energy consumption LEDs will give you fair and long-lasting lighting.

Download complete data sheet

Can be mounted on catenaries Download data sheet

Technical data

  • Aluminum integrable LED fixture with integrated heat sink and PMMA optics.
  • Dimensions: 206 x 72 mm
  • Protection: IP 65 / IK 08
  • Class: I(II possible)
  • Power: 12 W, 24 W
  • Outgoing flow: 1830 lm, 3360 lm
  • Color temperature: 2200, 2700, 3000 °K
  • CRI: >70
  • ULOR: <1%
  • Lifespan (L80B10): >100 000 h
  • Driver: Pilotage DALI, 0-10 V (sur demande)
  • Number of LEDs: 12
  • Vermentino

    Monobloc functional lighting fixture in extruded aluminum, rectangular section (200 x 120 mm). Heights: from 4 to 8 m.

  • Arbane

    Designed for decorative lighting applications, Arbane is an aluminum evolutive LED lighting structure in extruded aluminum, equiped with 3 to 5 brackets.
    Height: from 4.5 to 10 m.

  • Multipode

    Complete catenary lighting system made of aluminum poles between whom are drawn 3 stainless steel ropes allowing to hang up light fixtures.
    Height: from 4 to 6 m.

  • Reglisse

    Lighting structure in aluminum with supple, slender forms for functional and ambiant lighting.
    Height: from 4 to 8 m.
