Singular in its style and applications, Jeny has a triangular shape profile and is equipped with 3 technical grooves which facilitate accessorization. In tribute to Jenny Holzer, innovative artist in word expression, Jeny can be coupled with “LittleWords” from Technilum: an integrated LED screen allowing the interactive diffusion of messages or animations thanks to a dedicated application. Chic and playful!Download data sheet
Height 4 to 8 m (13’1 15/32” to 26′ 2 31/32”)
- Exclusive aluminum triangular profile, with internal functional structure and external technical grooves, to facilitate the mounting of accessories
- Mast profile: Jeny
- Profile dimension: 200 x 174 mm
- Made from a specific aluminum profile. Flush, interchangeable. Opening size 110×500 mm, located at 600 mm (23 5/8″) from the base (other height on demand). Locked with tamper-proof screw.
- Baseplate made of die-cast aluminum. Insulating rings on the 4 anchoring oblongs to avoid any contact with galvanized steel bolts. Construction entirely weld-free to eliminate weakness point: the connection pole/base plate is realized thanks to a two-part epoxy adhesive. Download here the full specifications.
- Single, double (120°) or triple (120°) pole top, in perfect harmony with the mast and manufactured in the same section.
- Number of arms: 1, 2, 3
- Standard outreach: 1 m (or 3′ 3 3/8″)
- Tilt: 10°
- Polyester powder coating: more than 200 colors available, plus special finish. Natural anodization available.
- Source: LED
- LED luminiare, 16 LEDs lighting, integrated LED driver and heat sink.
- Module type: Kareo
- Power: 16 W, 33 W
- Outgoing flow: 2385 lm, 4480 lm
- Lighting efficiency: 135-150 lm/w
- Color temperature: 2200, 2700, 3000, 4000°K
- CRI >70 (>80 possible)
- Optic: Asymmetrical wide beam, Asymmetrical medium, Symmetrical
- Protection: IP 66 / IK 05
- Class: 1 (2 possible)
- Programmable, dimmable (DALI or 0-10 V) or not dimmable
Communicate in a dynamic or even interactive way, always chic and fun! Technilum has developed a system of smart connected LED screens, managed from a hypervisor or an application called LittleWords©. Also developed by Technilum, this app offers a very simple management interface, allowing any authorized person, even non-specialist, to edit and program these animations. The possibilities of animation of the public space are multiple, via informative messages or graphic animations, broadcasted zone by zone, or to precise point(s), in a programmed way or in real time.
Sober and elegant, our Paul (square format) & Paulette (round format) projectors are available specifically for architectural lighting or roadway lighting. They are fully compatible with our entire range of our poles, lampposts, and lighting columns. Download complete data sheet Download photometric file 3000K (.ies) Download photometric file 3000K (.ldt)
Need more info ?
Feel free to contact us if you have any question.
