Integrated into a Ceramic Jules or Juliette, or Nerello envelope, the Magic™ LED fixture can be adapted to our entire range of lampposts. It is particularly suitable for pedestrian or ambient lighting and offers visual comfort to users.Can be mounted on catenaries
Technical data
- LED luminaire with die-cast aluminum body, extra-thin tempered glass, and Zhaga PCB.
Electrical connection via connector. - Dimensions: Ø250 x 83 mm
- Protection: IP 66 / IK 08 (IK10 sur demande / upon request)
- Class: I(II possible)
- Power: 35 W
- Outgoing flow: 4600 lm
- Color temperature: 2200, 2700, 3000, 4000 °K
- CRI: >70 (>80, >90 sur demande / upon request)
- ULOR: <1%
- Lifespan (L80B10): >109 000 h
- Driver: ON/OFF, Programmation Horaire, DALI-2 , Zhaga D4i, DMX, 0-10V, socket Zhaga / NEMA déporté sur le mât (sur demande / upon request)
- Number of LEDs: 24
-
AiguilleTapered aluminum pole for floodlight mounting, perfect for architectural and event lighting.
Heights: from 4.2 to 13.9 m.
Compatible with Texture Lighting floodlights -
MultipodeComplete catenary lighting system made of aluminum poles between whom are drawn 3 stainless steel ropes allowing to hang up light fixtures. Height: from 4 to 6 m.
Compatible with Texture Lighting floodlights -
NerelloAluminum lamp post for the ambient lighting of public spaces with customizable parts (head, arm…). Height: from 3.5 to 5 m.
-
Structure KAluminum poles range equipped with technical grooves to allow the positionning of light fixtures or accessories, for dimensional or scenographic lighting. Height: from 4 to 20 m. K120, K140, K160, K200, K250, K320 Texture Lighting
-
Ceramic (Jules & Juliette)LED aluminum lamp post for the ambient lighting of public spaces, made of noble material (ceramic and aluminum) and customizable (2 models: Jules & Juliette, 4 dispositions). Height: from 3,5 to 4,5 m.
-
RovelloLighting structure in aluminum with 1 to 4 bracket(s), for ambiant and functional lighting. Height: from 4 to 7 m.
-
Ceramic (applique)Led wall-mounted combining two noble materials, aluminum and ceramic for ambient public space lighting. Declined in several versions (Jules, Juliette)
-
Rovello (wall-mounted)Rovello wall-mounted lighting system, for ambient and decorative lighting
-
MauzacElegant and refined aluminum LED lamp post for ambient lighting. Rectangle Shiraz K profile with technical grooves to facilitate accessorization.
Height: from 3.5 to 5 m. -
RoussanneAluminum lamp post for functional lighting with simple or double head. Height: from 5 to 12 m.
-
EsplanadeLamppost for functional, ambient and decorative lighting with cylindrical aluminum profile.
-
Marsanne (wall-Mounted)Monobloc wall-mounted lighting systemmade of extruded aluminum, specially designed for ambient lighting.
Outreach: from 1 to 2 m. -
City LineAluminum light pole designed to provide functional lighting and highly versatile (pole profile, number and type of arms and pole heads).
Height: from 4 to 12 m. -
Mauzac (wall-mounted)Elegant wall-mounted lighting system for ambient lighting, made of 2 connected aluminum arms. Outreach: 1m.
-
Nerello (wall-mounted)Wall-mounted lighting system with contemporary silhouette. Outreach: 0,8 m.
-
GrenacheAluminum pole designed for dimensional and scenographic lighting. Provided with functionnal external grooves to fix floodlights, equipment and signposting.
Height: from 5 to 8 m.
Compatible with Texture Lighting floodlights -
OctaveOval aluminum light pole designed for dimensional and scenographic lighting, with 6 technical grooves to fix lighting fixtures or accessories. Height: from 3.5 to 8 m.
Compatible with Texture Lighting floodlights -
Roussanne (wall-mounted)Aluminum wall-mounted lighting system for functional lighting. Height: 0,5 m, 1 m or 1,5 m.
-
Roussanne (Variation)Lighting pole with single, double or quadruple open-work aluminum arm, designed for ambient or functional lighting. Height: from 5 to 12 m.
-
Techni-TramAluminum pole whose patented design demonstrates originality, lightness and transparency. Height: from 5 to 12 m.
