Mauzac

  • D_Mauzac_jour
  • D_Mauzac_nuit
  • D_Photometry_Magic

Mauzac relates to interior architectural lightings. Its refined aesthetics brings elegance and fineness to this object. Designed for external ambient and decorative lighting of public spaces, it is made of aluminum and is entirely weld-free. The arms’ height can be ajusted as needed. Equipped with an LED fixture, Mauzac contributes to reduce environmental footprint thanks to its extended life-span, reduced energy consumption and easy maintenance.

Height from 3.5 to 5 m (from 11′ 5 51/64″ to 16′ 4 27/32″)

Technical data

  • Exclusive rectangular aluminum profile with internal structure. 2 external technical grooves to facilitate accessorization (signage, bin, camera…).
  • Mast profile: Shiraz K Nano
  • Profile dimension: 158 x 95 mm (6 1/4″ x 3 3/4″)
  • Access door made from a specific aluminum profile. Flush, interchangeable. Opening 500×90 mm (19 11/16″ x 3 9/16″) at 600 mm (23 5/8″) from the base (other height on demand). Locked with tamper-proof screw.
  • Baseplate made of die-cast aluminum. Insulating rings on the 4 anchoring oblongs to avoid any contact with galvanized steel bolts. Construction entirely weld-free to eliminate weakness point: the connection pole/base plate is realized thanks to a two-part epoxy adhesive. Download here the full specifications
  • Assembly of 2 arms made of rectangular section aluminum profile, mounted on the mast’s sides. Fixture mounted to the arm through an articulation to allow on-site adjustment of the tilt.
  • Number of arms: 1, 2
  • Possible to add a pedestrian lighting (Technifonction)
  • Standard outreach: 1 m (or 3′ 3 3/8″)
  • Tilt: 0-15°
  • Polyester powder coating: more than 200 colors available, plus special finish. Natural anodization available.
  • Source: LED
  • LED luminaire fitted in the arm. Body made of die-cast aluminum, integrated LED driver and heat sink. Extra clear flat glass. 30 Leds lighting on aluminum PcB. Optical prism on each Led, different light distribution available..
  • Module type: Magic
  • Luminaire dimension: 250×83 mm (9 13/16″ x 3 1/4)
  • Power: 35 W
  • Outgoing flow: 3450 – 3592 lm
  • Lighting efficiency: 99 – 101 lm/W
  • Color temperature: 3000 K, 4000 K
  • CRI >70
  • Optic: Asymmetrical wide beam, Symmetrical, Asymmetrical
  • Protection: IP 65 / IK 08
  • Class: 1 (2 possible)
  • Programmable, dimmable (DALI or 0-10 V) or not dimmable
  • DEL intensity: 700 mA
